Warranty Length
5/25 years
Features
- Lead free design is suitable for all no lead potable water installations in full compliance of all lead free plumbing laws
- Each stop is individually packaged, preventing connection component loss and protecting the stop from contamination
- Thermoplastic stems (except sweat configurations) resist scale and debris build-up better than metallic stems, even in hard water conditions
- Traditional compact lead free brass body is machined from a single piece of barstock, providing the highest level of durability and strength
- Polished chrome brass handle screw, polished chrome die-cast brass handle polished chrome forged brass bonnet EPDM rubber stem packing, stainless steel anti-friction packing support washer, polished chrome lead free forged brass stem, polished chrome forged brass compression nut , lead free forged brass compression ferrule, EPDM rubber seat washer, lead free polished chrome forged brass body
- Forged brass body
- EPDM rubber seat washer
Standard Approvals
- ANSI/NSF Standard 61-G
- ANSI/ASME B1.20.1 (FNPT)
- ANSI/ASME B16.18 (CTS Solder)
- PROP65: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
- UPC/IAPMO Listed
- U.S. Federal Public Law 111-380
Body Material:
Brass
Domestic/Import:
Import
End Style:
C x Compression
Finish:
Polished Chrome
Media:
Water
Nominal Size:
1/2 x 3/8 in
Pressure Rating:
110 psi
Softgoods Material:
EPDM
Trim Material:
Forged Brass
