Ducane™ BCE5E60MA4X BCE5 Multi-Position Enhanced Compact Air Handler, 5 ton Nominal, 1 hp 208/230 V 53 A 1 ph 60 Hz
| Brand | Ducane™ |
| MFR Part No | 16G97 |
| TSCO Part Number | 1003998 |
- Features
- Specifications
- Documents
Warranty Length
- 10 years Limited on Parts and Compressor
Features
- Constant torque motor delivers consistent airflow for steadier temperatures and increased energy efficiency
- Omniguard™ total corrosion protection technology helps protect against corrosive elements extending the life of your unit for years to come
- Sealed cabinet is constructed for less than 2% air leakage to ensure maximum efficiency
Standard Approvals
- AHRI Certified
- cETLus Listed
Control Type:
Constant Torque
Cooling Capacity:
5.0 Ton Cooling
Filter Size:
18 x 20 in
Flow Rate:
1980 cfm
Fuse Size:
110 A
Heating Capacity:
No Heating Capacity
Liquid Line Size:
3/8 in
Motor Type:
Blower/Constant Torque
Nominal Capacity:
5 ton
Power Source:
1 hp 208/230 V 53 A 1 ph 60 Hz
Refrigerant Type:
R-410A
Suction Line Size:
7/8 in
Type:
Multi-Position Enhanced
Voltage Rating:
208/230v 1ph 60 hz
Efficiency:
Not Rated
Height:
63.3
Length:
25.5
Net Weight:
186.0
Width:
27.0
