Features
- ASTM D-1784: Rigid poly vinyl chloride (PVC) compounds and chlorinated poly vinyl chloride (CPVC) compounds
- ASTM D-2466: Socket type poly vinyl chloride (PVC) plastic pipe fittings, SCH 40/STD
- ASTM F-1970: Standard specification for special engineered fittings, appurtenances or valves for use in poly vinyl chloride (PVC) or chlorinated poly vinyl chloride (CPVC) systems
- Material: Lasco® SCH 40/STD fittings are produced from PVC type 1, cell classification 12454-B
- NSF/ANSI standard 61, Annex G: Drinking water system components weighted average lead content of less than or equal to 0.25% and is in compliance with California's health and safety code section 116875 (commonly known as AB1953) NSF/ANSI Standard 14: Plastics piping system components and related materials, includes ANSI standard 61, Annex G
- Not to be used in the hot or cold water distribution system in a dwelling maximum service temperature 140 deg F
- Do not use Lasco® fittings for compressed air or gases
- Do not test PVC piping systems with compressed air or gases
- Do not use fittings with liquids not recommended by Lasco®
- Fitting modification voids the warranty
Standard Approvals
- ASTM D1784
- ASTM D2466
- ASTM F1970
- NSF/ANSI 14
- NSF/ANSI 61
- Annex-G
Color:
White
Domestic/Import:
Domestic
End Style:
Spigot x Slip
Material:
PVC
Method of Manufacture:
Injection-Molded
Nominal Size:
1-1/4 in
Fitting/Connector Type:
90 deg Elbow
Pressure Rating:
370 psi
Schedule Rating:
SCH 40/STD
Temperature Rating:
73 deg F
Seal Material:
Buna-N O-Ring
