Cash Acme®
Cash Acme® TANK BOOSTER™ 24643 Tank Booster, 3/4 in, MNPT x FNPT x NPSH, 150 psi, Brass Body
Cash Acme®

Cash Acme® TANK BOOSTER™ 24643 Tank Booster, 3/4 in, MNPT x FNPT x NPSH, 150 psi, Brass Body

BrandCash Acme®
MFR Part No24643
TSCO Part Number548199

Warranty Length

  • 5 Years

Features

  • Precise temperature control: Safer hot water from all outlets
  • Allows the water heater to be set at 140 deg F (60 deg C) or higher: Greater effective hot water volume and less chance of Legionella within the cylinder
  • Every valve is tested for performance prior to shipping: Specify and install with confidence
  • More hot water from the same water heater: Higher storage temperature means a greater effective hot water volume delivered at a safe 120 deg F (49 deg C)
  • Robust, low complexity construction: Superior reliability, improved user safety
  • Adjustable and lockable mechanism: Minimizes unauthorized tampering with valve setting, Factory set at 120 deg F (49 deg C)
  • Listed by IAPMO and ASSE: Inspector friendly, peace of mind
  • Integral recirculation port: Allows quick and neat installations in systems with recirculation
  • Includes the Tank Booster Temperature Gauge: Allows visual verification of water outlet temperature
  • 195 deg F Max hot temperature supply range
  • 39 to 80 deg F cold temperature supply range
  • Stainless steel springs
  • Brass internal cap
  • Engineered polymer piston
  • Noryl GFN2 guide tube
  • 115 to 120 deg F factory setting
  • 120 to 180 deg F hot temperature supply

Standard Approvals

  • ASSE 1017
  • ASSE 1070
  • CSA B125.3
  • ANSI/NSF 61/372
  • NSF 61/372
  • Listed by ASSE
  • IAPMO
  • UPC Listed
